PIPL75W24 Switch Mode Power Supply
Description
| Output Voltage | DC 24V |
| Output Current | 6A |
| Output Power | 75W |
| Brand | Powertron |
| Load Regulation | +/- 0.5% |
| Efficiency | >85.00% |
| Mounting Style | DIN-Rail Mount |
| Rise Time | 50mS |
| Model Name/Number | PIPL75W24 |
| Country of Origin | Made in India |
| Setup Time | 800mS |
| Line Regulation | +/- 0.3% |
| Ripple / Noise | 150mVp-p |
| Hold Time | 20mS |
| AC Input Voltage | AC 264V |
| output Voltage Adjustment Range | +/-10% By Potentiometer |
| Dimension (L x W x H) | 114 x 40 x 126mm |
| DC Input Voltage | DC 350V |
